High-Speed Wired and Wireless Connectivity

Lightning-fast Wi-Fi speeds of up to 1200 Mbps1 and Gigabit parts. So you can meet the ever-greater demand from multimedia applications.

DIR-842-ac1200-high-speed

Dual-Band Wireless for Seamless Performance

Surf the web, chat and play online games on the 2.4 GHz band with your smartphones and computers, while silmutaneously streaming digital media on the 5GHz band on your streaming media players and tablets.

DIR-842-ac1200-dualband

MU-MIMO

DIR-842-MUMIMO

(MU-MIMO available on DIR-842 Hardware C1)

DIR-842-ac1200-highgain-antenna

4 x 5dBi High Gain Antennas Provide Better Coverage

Four external High Gain Antenna give you a wider wifi coverage and better performance.

Advanced QoS

Bandwidth Optimization through check prioritization

DIR-842-ac1200-advanced-QOS

D-Link QRS™ Mobile

Now you can set up your home network right from your iPhone® or iPad or Android phone. Imagine being able to get your QRS (Quick Router Setup) Mobile-enabled router up and running in no time from the comfort of your couch of favourite chair – no more need to hunch over a computer to set up your network. Just follow the simple instructions to get started.

DIR-842-ac1200-dlink-QRS

IPv6 Ready

Future-Proof your investment by supporting the new IPv6 Standard.

Specifications


Device Interfaces • IEEE 802.11 ac/n/g/b/a wireless LAN
• 10/100/1000 Gigabit EthernetWAN port
• Four 10/100/1000 Gigabit Ethernet LAN ports
LEDs • Power
• Internet
• WLAN
• LAN (x4)
• WPS
Antenna Type • Four external antennas
Operating Frequency • 2.4 GHz band: 2400 - 2483.5 MHz
• 5 GHz band: 5150 - 5725 MHz
Standards • IEEE 802.11ac
• IEEE 802.11n
• IEEE 802.11g
• IEEE 802.3ab
Minimum Requirements • Windows 8/7/Vista or MAC OS X 10.6 or higher
• Internet Explorer 9, Firefox 20.0, Chrome 25.0, Safari 5.1, or other Java-enabled browse
• Network interface card
• Cable/DSL modem or other Internet Service Provider equipment with Ethernet port
Security • WPA &WPA2 (Wi-Fi Protected Access)
• WPS (Wi-Fi Protected Setup)
Advanced Features •Web setup wizard
• QoS (Quality of Service)
• DMZ (Demilitarized Zone)
• Firewall - Network Address Translation (NAT)
• Guest zone • IPv6 ready
